CP Plus CP-UNP-F4541L30-DPQ is a professional-grade 4MP Network PTZ Camera featuring powerful 45X optical zoom, 16X digital zoom and up to 300-meter IR night vision. With 120dB WDR, Starlight technology, Auto Tracking, intelligent video analytics, PoE+ support and IP67/IK10 protection, it is designed for long-range surveillance of large outdoor areas, industrial sites, campuses, highways and perimeter security.
Key Features
4MP High-Resolution Network PTZ Camera
1/2.8" 4MP PS CMOS image sensor
Resolution up to 2688 × 1520
Up to 25/30fps
45X Optical Zoom
16X Digital Zoom
3.95mm–177.75mm motorized lens
120dB WDR
Starlight technology
300m IR Night Vision
6 IR LEDs
Day/Night with ICR
2D & 3D Noise Reduction
Defog
BLC / HLC / AWB
ROI support
Triple-stream video
H.265 / H.264 / MJPEG compression
360° Endless Pan
Tilt: -20° to +90°
Auto Flip 180°
Up to 300 Presets
8 Tours
5 Scan paths
5 Patterns
Auto Tracking
Electronic Image Stabilization (EIS)
Motion Detection
IVS / Perimeter Protection
Face Detection & Face Enhancement
MicroSD support up to 512GB
Audio Input & Audio Output
7 Alarm Inputs / 2 Alarm Outputs
PoE+ (802.3at) support
24V DC power option
IP67 Weatherproof
IK10 Impact Protection
6000V TVS lightning protection
ONVIF Profile S, G & T
IPv4 / IPv6
RJ45 10/100 Ethernet
iCMOB & gCMOB mobile applications
KVMS Pro Lite / EVMS Pro CMS support

PTZ & Zoom Specifications
Specification
Details
Resolution
4MP
Maximum Resolution
2688 × 1520
Optical Zoom
45X
Digital Zoom
16X
Pan
0°–360° Endless
Tilt
-20° to +90°
Presets
Up to 300
Tour
8
Scan
5
Pattern
5
Auto Tracking
Yes
IR Distance
300m
WDR
120dB

Video & Network
Video Compression: H.265, H.264, H.264H, H.264B, MJPEG
Triple Stream
Bit Rate: H.265 up to 8192 Kbps
Ethernet: RJ45 10/100 Base-T
ONVIF: Profile S / G / T
RTSP / RTMP / SMTP / SFTP
IPv4 / IPv6
HTTPS / TLS
SNMP
NAS / FTP support
Maximum 20 users
Up to 64 Mbps bandwidth
AI / Intelligent Features
Auto Tracking
Face Detection
Face Enhancement
Face Snapshot
Tripwire
Intrusion Detection
Missing Object Detection
Abandoned Object Detection
Loitering Detection
Fast Moving Detection
Parking Detection
Crowd Gathering
Intelligent Motion Detection
Motion Detection
Video Tampering
Audio Detection
Protection & Environmental Specifications
IP67 Weather Protection
IK10 Impact Resistance
6000V Lightning Protection
Surge Protection
Voltage Transient Protection
Operating Temperature: -40°C to +70°C
Operating Humidity: ≤95% RH
Storage & Audio
MicroSD Card Support: Up to 512GB
1 × Audio Input
1 × Audio Output
PCM / G.711A / G.711MU / G.726 / MPEG2-Layer2 / G.722.1
Power
24V DC, 2.5A ±25%
PoE+ 802.3at
Basic Consumption: Approx. 13W
Maximum Consumption: Approx. 25W with IR + PTZ
